| Name |
Description |
Features |
Application Areas |
| ISO |
ISO Metric Full Profile Thread Insert is a tool with a complete thread profile, designed to meet ISO Metric thread standards. |
Complying with ISO standards ensures that the processed threads have uniform size and precision, and the full-profile design improves processing efficiency. Made of high-quality materials, with high hardness and wear resistance
|
- ISO metric full-tooth thread inserts are widely used in machinery manufacturing, automobile manufacturing, aerospace, petrochemical and other fields.
|
| W |
Threads specially designed for pipe connections |
The tooth angle of Whitworth thread is 55°, which is different from many other thread standards. The rounded top and bottom of the thread can reduce the wear of the thread tool on the top and improve its fatigue resistance. |
- Oil drilling: Whitworth threads can ensure the tightness and tensile strength of the connection.
- Pipeline system: Applicable to pipeline systems in the oil, natural gas, chemical and other industries.
- Manufacturing: In the manufacturing industry, Whitworth threads are also often used in situations where high-precision and reliable connections are required.
|
| TR |
30° Trapezoidal thread |
Trapezoidal thread refers to a metric trapezoidal thread with a tooth angle of 30°.Trapezoidal threads are mainly used for transmission, have high strength and rigidity requirements, are not easy to loosen, and have high transmission efficiency. |
- Trapezoidal threads are widely used in CNC machine tools, automated production lines, heavy equipment, etc.
|
| ACME |
ACME trapezoidal thread cutter is a tool specially designed for processing ACME trapezoidal threads, with specific angle and shape design. |
The ACME thread usually has a tooth angle of 29° (there are other angles such as 30°, but 29° is the most common), and the tooth profile is trapezoidal, wider at the bottom and narrower at the top.
|
- Mechanical connection: ACME trapezoidal threads are often used to connect key components such as shafts, gears, and bearings.
- Transmission system: In the transmission system, ACME trapezoidal threads can be used to transmit torque and power.
- Oil and gas industry: ACME trapezoidal threads are often used to connect key equipment such as pipelines and valves.
- Other industrial fields: It is widely used in metallurgy, chemical industry, textile and other industries.
|
| UNJ |
UNJ thread is a mechanical thread with high strength and durability, especially suitable for applications requiring high strength and reliable connection. |
High strength: Compared with cUNJ threads have higher strength. The external thread bottom of UNJ threads is in an arc shape. This design helps to reduce stress concentration and increase the fatigue life of the threads.
|
- UNJ threads are widely used in aerospace, defense and related industries.
|
| NPT |
The NPT thread has a tooth angle of 60° and a taper of 1:16. |
NPT threads can provide reliable sealing performance. NPT threads comply with the US National Pipe Thread Standard (ANSI/ASME B1.20.1, etc.) and have good versatility and interchangeability.
|
- Pipeline system: NPT threaded connectors are often used for fastening, sealing and connection.
- Petroleum and chemical industry: In water pumps, pipelines and valves in oil wells, NPT connectors are used for connection and sealing.
- Compressed air system: NPT threaded connectors are used to connect compressed air pipes, air filters, air dryers and other equipment and components.
- Other industrial fields: NPT threads are also often used for branch connections of various pipeline systems.
|
| NPTF |
NPTF thread is a thread standard for pipe connections developed by the American National Standards Institute (ANSI), mainly used in North America. |
Sharp tooth shape and short root: higher connection stability and security. NPTF thread has good self-locking performance, can provide greater load-bearing capacity, high tooth shape accuracy, and can prevent leakage without sealing medium.
|
- Pipeline systems: NPTF threaded joints are often used for tightening, sealing and connection.
- High-pressure systems: NPTF threads are particularly suitable for high-pressure systems because they can prevent leakage without sealing media.
- Large equipment and projects: Due to the large load-bearing capacity of NPTF threads, they are also widely used in some large equipment and projects.
|
